The Tennis Court

Tennis Court Dimensions: The Official Measurements

78 feet is the standard distance from baseline to baseline, according to the tennis court dimensions reference.

Court and net measurements

The International Tennis Federation, or ITF, sets the measurements for a tennis court, according to the tennis court reference. The dimensions apply to the markings, the net and the location of its supports. The clearance row describes the overall area, including the room left outside the lines for play. Metric values in parentheses follow the same reference.

Measurements of the standard tennis court and net
What is measuredMeasurementReference
Length between baselines78 ft (23.77 m)Court dimensions
Singles width27 ft (8.23 m)Court dimensions
Doubles width36 ft (10.97 m)Court dimensions
Net to service line21 ft (6.40 m)Court dimensions
Net height at posts3 ft 6 in (1.07 m)Court dimensions
Net height at center3 ft (0.914 m)Court dimensions
Post position on each side3 ft (0.914 m) outside the doubles court for a doubles net, or outside the singles court for a singles netCourt dimensions
Center service line width2 in (5 cm)Line measurements
Ordinary line widths1 to 2 in (3 and 5 cm)Line measurements
Maximum baseline width4 in (10 cm)Line measurements
Clear area including the court60 ft (18 m) wide by 120 ft (37 m) longCourt dimensions

The edges of the marked court

The baseline is the rear edge for singles and doubles, so changing from one format to the other leaves the court's length alone. The width changes because the singles sidelines lie inside the doubles sidelines. The gap on each side forms an alley, as the court terminology describes. In the top-down court diagram, the outer span shows the width for a doubles rally and the inner span shows the width for a singles rally.

The measurement reference specifies measuring to the outside of the relevant baselines and sidelines. The full painted width is inside the boundary. Where a baseline is wider than other markings, its outside edge still determines where the court ends. This is how the measurement convention and the line rule fit together: the outer edge is the edge of the court, and a bounce that touches the line is inside.

The service markings sit within that rectangle. The service lines run parallel to the net and the center service line splits the space nearer the net into boxes on the left and right. The singles and doubles widths in the table describe the full rally court for each format. The outer edge of a service box is the singles sideline in both formats. The court terminology also identifies the center mark as a 4-inch mark at the midpoint of the baseline.

Net heights and post placement

The net sits across the middle of the rectangle, parallel to the two baselines. The net dimensions specify both the measurement at the posts and the lower one in the middle. These are measurements upward from the court. The post offset is measured outward from the corresponding sidelines. Since the singles sidelines are farther in, a net set up for singles uses a different reference line for locating those supports.

The space needed around the rectangle

The listed clearance is an overall envelope around the court. The court dimensions reference describes extra room both behind the base of play at each end and beyond the side edges, so players can reach balls that run past a line after a valid bounce. A court centered in that envelope leaves equal spaces at its ends and equal strips along its sides. The overall figures describe the full span in both directions.

A player might take a deep ball beyond the baseline or reach for a shot that bounces near a sideline and continues farther outward. The court's dimensions and line rule define the landing boundary, while the surround gives a player room to move after the bounce. For the layers of material under those markings, the court history describes how a lined court can be made of grass, clay or a hard surface.

Smaller court formats

The tennis court reference describes the ITF orange court as 59 ft (18 m) long by 21 ft (6.4 m) wide and the red court as 36 ft (11 m) long by 18 ft (5.5 m) wide, with a net height of 0.8 m at the center in these formats, according to its smaller-court section. The same reference describes orange-court competition for children aged 10 years and under and red-court competition for children under 8 years. It also describes the ITF's use of slower balls in child-friendly play so that players have more time to return the ball and experience a rally.

The equipment varies along with the court. The reference on slower tennis balls describes red balls made from foam rubber or oversized and unpressurized, orange balls of normal size without pressure, and green balls of normal size at half pressure. The labels describe ball categories. The court measurements above show how the space can vary at the same time as the pace of the ball, a pairing the adult beginner reference also discusses.
